FP2-D120-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FLAT-PAC Nonstandard 0.283Lx0.264W 7.20mmx6.70mm 120nH
PDF
/
Buying Options
Total Price: USD $2.03
Unit Price: USD $2.0328
≥1 USD $2.0328
≥10 USD $1.7248
≥100 USD $1.58928
≥500 USD $1.420144
≥1000 USD $1.183512
≥3000 USD $1.149667
Inventory: 1099
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 4
Weight 907.18474mg
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2007
Series FLAT-PAC
Size / Dimension 0.283Lx0.264W 7.20mmx6.70mm
Tolerance ±15%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 37A
Shielding Unshielded
Depth 6.7mm
Current Rating 37A
Military Standard Not
Inductance 120nH
Test Frequency 1MHz
DC Resistance (DCR) 0.26mOhm
Max DC Current 18A
Inductance Frequency - Test 1MHz
Current - Saturation 18A
Dimensions
Height 3mm
Height Seated (Max) 0.118 3.00mm
Length 7.1882mm
Width 6.7056mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
