SDED20161T-2R2MS
RoHS
RoHS compliant
RoHS compliantPackage 0806 (2016 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Active Tape & Reel (TR) Surface Mount Fixed Inductor -55C~125C 1MHz 230mOhm Max 2.2muH
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
≥10 USD $0.17336
≥100 USD $0.159808
≥500 USD $0.146608
≥1000 USD $0.12936
≥3000 USD $0.125312
Inventory: 1090
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 0806 (2016 Metric)
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series SDED20161T
Size / Dimension 0.079Lx0.063W 2.00mmx1.60mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 1.35A
Shielding Shielded
Inductance 2.2μH
DC Resistance (DCR) 230mOhm Max
Inductance Frequency - Test 1MHz
Current - Saturation 1.31A
Dimensions
Height Seated (Max) 0.039 1.00mm
Compliance
RoHS Status ROHS3 Compliant
