CMLB063T-3R3MS
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Active Tape & Reel (TR) Metal fixed air core inductor -55C~125C 100kHz 22mOhm Max 3.3muH
PDF
/
Inventory: 7262
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Metal
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series CMLB063T
Size / Dimension 0.274Lx0.260W 6.95mmx6.60mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Current Rating (Amps) 7.2A
Shielding Shielded
Inductance 3.3μH
DC Resistance (DCR) 22mOhm Max
Inductance Frequency - Test 100kHz
Current - Saturation 8.5A
Dimensions
Height Seated (Max) 0.118 3.00mm
Compliance
RoHS Status ROHS3 Compliant
