CMLB063T-150MS
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Active Tape & Reel (TR) Metal fixed air core inductor -55C~125C 100kHz 150mOhm Max 15muH
PDF
/
Inventory: 10042
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.118 3.00mm
Technical
Current - Saturation 3.3A
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 150mOhm Max
Inductance 15μH
Shielding Shielded
Current Rating (Amps) 2.7A
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.274Lx0.260W 6.95mmx6.60mm
Series CMLB063T
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Metal
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
