HCB0750-700L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND Fixed Inductor -40C~125C 100kHz 0.19mOhm 70nH
PDF
/
Buying Options
Total Price: USD $2.13
Unit Price: USD $2.1296
≥1 USD $2.1296
≥10 USD $1.8128
≥100 USD $1.670944
≥500 USD $1.493184
≥1000 USD $1.24432
≥3000 USD $1.208768
Inventory: 1214
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape WRAPAROUND
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series HCB0750
Size / Dimension 0.283Lx0.276W 7.20mmx7.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
HTS Code 8504.50.80.00
Current Rating (Amps) 48A
Shielding Unshielded
Number of Functions 1
Inductance 70nH
Test Frequency 0.1MHz
DC Resistance (DCR) 0.19mOhm
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductance Frequency - Test 100kHz
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 75A
Dimensions
Height Seated (Max) 0.205 5.20mm
Compliance
RoHS Status ROHS3 Compliant
