0603CS-301EJTS
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active WRAPAROUND Fixed Inductor -40C~125C 750MHz 2.5Ohm 300nH
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.187036
≥1 USD $0.187036
≥200 USD $0.074625
≥500 USD $0.072131
≥1000 USD $0.07091
Inventory: 5461
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Ceramic
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series 0603CS
Size / Dimension 0.071Lx0.046W 1.80mmx1.16mm
Tolerance ±5%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Current Rating (Amps) 150mA
Shielding NO
Number of Functions 1
Inductance 300nH
Test Frequency 100MHz
DC Resistance (DCR) 2.5Ohm
Frequency - Self Resonant 750MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 25 @ 100MHz
Quality Factor-Min (at L-nom) 25
Inductance Frequency - Test 100MHz
Rated Current-Max 0.15A
Dimensions
Height Seated (Max) 0.040 1.02mm
Compliance
RoHS Status ROHS3 Compliant
