0603CC-100EJTS
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active WRAPAROUND Fixed Inductor -40C~125C 3.7GHz 71mOhm 10nH
PDF
/
Inventory: 3621
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.040 1.02mm
Technical
Rated Current-Max 2A
Inductance Frequency - Test 250MHz
Quality Factor-Min (at L-nom) 38
Q @ Freq 38 @ 250MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 3.7GHz
DC Resistance (DCR) 71mOhm
Test Frequency 250MHz
Inductance 10nH
Number of Functions 1
Shielding Unshielded
Current Rating (Amps) 2A
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.071Lx0.044W 1.80mmx1.12mm
Series 0603CC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
