0402HP-3N3EKTS
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
0402HP 0402 (1005Metric) 0.045Lx0.028W 1.15mmx0.70mm 3.3nH
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.16192
≥100 USD $0.149248
≥500 USD $0.136928
≥1000 USD $0.120736
≥3000 USD $0.11697
Inventory: 6798
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.024 0.60mm
Technical
Special Feature Q MEASURED AT 900MHZ
Rated Current-Max 1.7A
Inductance Frequency - Test 250MHz
Quality Factor-Min (at L-nom) 66
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 12.8GHz
DC Resistance (DCR) 45mOhm
Test Frequency 250MHz
Inductance 3.3nH
Number of Functions 1
Shielding Unshielded
Current Rating (Amps) 1.7A
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.045Lx0.028W 1.15mmx0.70mm
Series 0402HP
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
