MP2-330-R

Coiltronics
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description RoHS Compliant Lead Free Tape & Reel Ferrite (Type) Inductor 85C 35MHz 556mOhm 33muH
PDF
/
Inventory: 5402
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 5.1816mm
Length 7.493mm
Height Seated (Max) 1.8034mm
Height 1.8mm

Technical

DC Resistance (DCR) - Parallel 556mOhm
Q Factor 65
Current - Saturation 370mA
Frequency - Self Resonant 35MHz
Max DC Current 370mA
Test Frequency 100kHz
Inductance 33 μH
Current Rating 640mA
Depth 5.2mm
Shielding Unshielded
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Termination SMD/SMT
Tolerance 20%
Packaging Tape & Reel

Physical

Material - Core Ferrite
Weight 907.18474mg
Number of Pins 2
Package / Case Nonstandard
Mount Surface Mount
