CTX50-3A-R
RoHS
/
Package SMD/SMT
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Lead Free Cut Tape (Type) Inductor 85C 100kHz 171mOhm 49.71muH
PDF
/
Inventory: 7206
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 13.97mm
Length 13.97mm
Height 4.83mm
Technical
Number of Coils 2
Inductance - Series 198.8 μH
Inductance - Parallel 49.71 μH
Inductance Tolerance 25%
DC Resistance (DCR) - Parallel 171mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Max DC Current 1.32A
Current 780mA
Test Frequency 100kHz
Inductance 50 μH
Military Standard Not
Depth 13.97mm
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Tolerance 25%
Packaging Cut Tape
Physical
Material - Core Metal
Weight 1.814369g
Number of Pins 4
Package / Case SMD/SMT
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
