CTX25-3A-R
RoHS
/
Package Metal
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Lead Free 2012 (Type) Inductor 85C 76mOhm 24.77muH 25%
PDF
/
Inventory: 3405
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 13.97mm
Length 13.97mm
Height 4.826mm
Technical
DC Resistance (DCR) - Series 306mOhm
Number of Coils 2
Inductance - Series 99.07 μH
Inductance - Parallel 24.77 μH
DC Resistance (DCR) - Parallel 76mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Max DC Current 1.88A
Current 1.17A
Inductance 25 μH
Current Rating 2.34A
Shielding Unshielded
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 76mOhm
Termination SMD/SMT
Tolerance 25%
Published 2012
Physical
Weight 453.59237mg
Number of Pins 4
Package / Case Metal
Mount Surface Mount
