XPL2010-501MLB

Coilcraft
RoHS
/
Package SMD/SMT
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant Contains Lead ONE SURFACE fixed air core inductor 85C 218MHz 45mOhm 500nH
PDF
/
Inventory: 2879
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Width 2.1mm
Length 2.2mm
Height 1mm

Technical

RMS Current (Irms) 2.3A
Inductance-Nom (L) 0.5 μH
Inductance Tolerance 20%
DC Resistance (DCR) - Parallel 45mOhm
Case/Size Code 0808
Current - Saturation 1.8A
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 218MHz
Max DC Current 2.3A
Test Frequency 100kHz
Inductance 500 nH
Reference Standard AEC-Q200
Construction Rectangular
Number of Functions 1
Shielding Shielded
Packing Method TR
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin/Silver/Copper -Matte Tin -with Nickel barrier
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
Tolerance 20%
Packaging Cut Tape

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Composite
Terminal Shape ONE SURFACE
Package / Case SMD/SMT
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 6 hours ago)
