SPT30L-353MLB
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant Contains Lead WRAPAROUND Fixed Inductor 85C 12MHz 166mOhm 35muH
PDF
/
Inventory: 8077
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 hours ago)
Physical
Surface Mount YES
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Bulk
Tolerance 20%
JESD-609 Code e2
Pbfree Code yes
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Silver (Sn/Ag)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method TR
Shielding Shielded
Number of Functions 1
Construction Toroidal
Inductance 35 μH
Test Frequency 100kHz
Max DC Current 1.6A
Frequency - Self Resonant 12MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 4444
DC Resistance (DCR) - Parallel 166mOhm
Inductance-Nom (L) 35 μH
Dimensions
Height 9.5mm
Length 11.18mm
Width 11.05mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
