1206CS-181XJLC

Coilcraft
RoHS
/
Package 1206
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant Contains Lead WRAPAROUND Fixed Inductor 125C 900MHz 430mOhm 180nH
PDF
/
Buying Options
Total Price: USD $20.65
Unit Price: USD $20.65205
≥1 USD $20.65205
≥10 USD $16.94515
≥100 USD $16.416
≥500 USD $15.8859
≥1000 USD $15.35675
Inventory: 1190
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status RoHS Compliant

Dimensions

Width 2.16mm
Length 3.56mm
Height 1.52mm

Technical

Special Feature Q IS MEASURED AT : 300 MHZ
Inductance-Nom (L) 0.18 μH
DC Resistance (DCR) - Parallel 430mOhm
Case/Size Code 1408
Q Factor 60
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 60
Terminal Placement DUAL ENDED
Frequency - Self Resonant 900MHz
Max DC Current 700mA
Test Frequency 50MHz
Inductance 180 nH
Reference Standard AEC-Q200
Construction Rectangular
Number of Functions 1
Shielding NO
Packing Method TR, Embossed Plastic, 7 Inch
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Silver/Palladium/Platinum - with Glass frit
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Pbfree Code yes
Tolerance 5%

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Weight 10.007382mg
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 1206

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 hours ago)
