0603HP-10NXGLU
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description
10nH 2% 2%
PDF
/
Inventory: 2991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 1.09mm
Length 1.75mm
Height 940μm
Technical
Inductance-Nom (L) 0.01 μH
Inductance Tolerance 2%
DC Resistance (DCR) - Parallel 48mOhm
Q Factor 142
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 4.3GHz
Max DC Current 1.4A
Test Frequency 250MHz
Inductance 10 nH
Case Code (Imperial) 0603
Case Code (Metric) 1608
Current Rating 1.4A
Construction Rectangular
Number of Functions 1
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Silver/Palladium/Platinum - with Glass frit
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Part Status Active
Pbfree Code yes
Tolerance 2%
Published 2012
Packaging Cut Tape
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Terminal Shape WRAPAROUND
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 hours ago)
