BWCS001610088N2G00
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
RF INDUCTOR WW
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
≥10 USD $0.13288
≥100 USD $0.122144
≥500 USD $0.107712
≥1000 USD $0.094248
≥3000 USD $0.08976
Inventory: 1521
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.040 1.02mm
Technical
Inductance Frequency - Test 250MHz
Q @ Freq 28 @ 250MHz
Frequency - Self Resonant 4.7GHz
DC Resistance (DCR) 109mOhm Max
Inductance 8.2nH
Shielding Unshielded
Current Rating (Amps) 700mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±2%
Size / Dimension 0.063Lx0.040W 1.60mmx1.02mm
Series BWCS
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ceramic
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
