BSCH000603032N2S00
RoHS
RoHS compliant
RoHS compliantPackage 0201 (0603 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
BSCH 0201 (0603Metric) 0.024Lx0.012W 0.60mmx0.30mm 2.2nH
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.02112
≥100 USD $0.020064
≥500 USD $0.016896
≥1000 USD $0.014344
≥3000 USD $0.013693
Inventory: 98676
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.013 0.33mm
Technical
Rated Current-Max 0.36A
Inductance Frequency - Test 100MHz
Quality Factor-Min (at L-nom) 4
Q @ Freq 4 @ 100MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 8.8GHz
DC Resistance (DCR) 190mOhm Max
Test Frequency 100MHz
Inductance 2.2nH
Number of Functions 1
Shielding Unshielded
Current Rating (Amps) 360mA
Type Multilayer
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±0.3nH
Size / Dimension 0.024Lx0.012W 0.60mmx0.30mm
Series BSCH
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Terminal Shape WRAPAROUND
Surface Mount YES
Package / Case 0201 (0603 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
