SRU1048A-100Y
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRU1048A Nonstandard 0.394Lx0.394W 10.00mmx10.00mm 10muH
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9944
≥1 USD $0.9944
≥10 USD $0.84392
≥100 USD $0.767008
≥500 USD $0.721072
≥1000 USD $0.598312
≥3000 USD $0.552253
Inventory: 3016
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2013
Series SRU1048A
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Tolerance ±30%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Depth 10.3mm
Current Rating 4.5A
Military Standard Not
Inductance 10μH
Test Frequency 100kHz
DC Resistance (DCR) 25mOhm Max
Max DC Current 4.5A
Frequency - Self Resonant 16MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 26 @ 2.52MHz
Current - Saturation 3.7A
Case/Size Code 3939
Inductance Tolerance 30%
RMS Current (Irms) 4.5A
Dimensions
Height 4.8mm
Height Seated (Max) 0.201 5.10mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
