SRR1280-271V4K
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRR1280 Nonstandard 0.492Lx0.492W 12.50mmx12.50mm 270muH
PDF
/
Inventory: 1776
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 12.4968mm
Length 12.4968mm
Height Seated (Max) 0.315 8.00mm
Technical
Current - Saturation 1.6A
Inductance Frequency - Test 100kHz
Q @ Freq 20 @ 796kHz
Frequency - Self Resonant 3.1MHz
DC Resistance (DCR) 450mOhm Max
Test Frequency 100kHz
Inductance 270μH
Base Part Number SRR1280
Current Rating 1.2A
Shielding Shielded
Current Rating (Amps) 1.2A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Tolerance ±10%
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Series SRR1280
Published 2011
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
