SRR1210A-102M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRR1210A Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 1mH
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.3112
≥1 USD $1.3112
≥10 USD $1.10704
≥100 USD $1.006368
≥500 USD $0.946
≥1000 USD $0.78496
Inventory: 902
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height Seated (Max) 0.394 10.00mm
Technical
RMS Current (Irms) 750mA
Inductance Tolerance 20%
Current - Saturation 700mA
Inductor Type GENERAL PURPOSE INDUCTOR
Q @ Freq 22 @ 796kHz
Frequency - Self Resonant 850kHz
DC Resistance (DCR) 1.65Ohm Max
Test Frequency 1kHz
Inductance 1mH
Current Rating 750mA
Shielding Shielded
HTS Code 8504.50.80.00
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Series SRR1210A
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
