SRP7030-220M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED INDUCTOR 22UH SMD
PDF
/
Inventory: 7230
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.0104mm
Length 7.7978mm
Height Seated (Max) 0.126 3.20mm
Technical
Inductance Frequency - Test 100kHz
Test Frequency 100kHz
Inductance 22μH
Base Part Number SRP7030
Shielding Shielded
Composition Wirewound
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.307Lx0.276W 7.80mmx7.00mm
Series SRP7030
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Iron
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
