SRP6540-470M image
Favorite
SRP6540-470M image
Favorite

SRP6540-470M

Bourns Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description SRP6540 Nonstandard 0.283Lx0.256W 7.20mmx6.50mm 47muH
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.8184
≥100 USD $0.753984
≥500 USD $0.673728
≥1000 USD $0.564872
Inventory: 8015
Minimum: 1
-
+

Technical Details

Technical

Packaging Cut Tape (CT)
Published 2006
Series SRP6540
Size / Dimension 0.283Lx0.256W 7.20mmx6.50mm
Tolerance ±20%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8504.50.80.00
Packing Method TR, EMBOSSED, 13 INCH
Shielding YES
Number of Functions 1
Depth 6.7mm
Construction Rectangular
Current Rating 1.6A
Military Standard Not
Inductance 47μH
Test Frequency 100kHz
DC Resistance (DCR) 366mOhm Max
Max DC Current 1.6A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Inductance Tolerance 20%
RMS Current (Irms) 1.6A
Self Resonant Frequency 100kHz
Operating Temperature -55°C~125°C

Dimensions

Height 4mm
Height Seated (Max) 0.157 4.00mm

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Iron Powder
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 15 Weeks

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
