SRP1206-3R3Z
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRP1206 Nonstandard 0.492Lx0.492W 12.50mmx12.50mm 3.3muH
PDF
/
Inventory: 1694
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -55°C~150°C
Packaging Tape & Reel (TR)
Published 2011
Series SRP1206
Size / Dimension 0.492Lx0.492W 12.50mmx12.50mm
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Current Rating (Amps) 14A
Shielding Shielded
Current Rating 14A
Base Part Number SRP1206
Inductance 3.3μH
Test Frequency 100kHz
DC Resistance (DCR) 7mOhm Max
Inductance Frequency - Test 100kHz
Current - Saturation 12A
Dimensions
Height 5.6896mm
Height Seated (Max) 0.236 6.00mm
Length 12.4968mm
Width 12.4968mm
Compliance
RoHS Status ROHS3 Compliant
