SRN4012-6R8M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRN4012 Nonstandard 0.157Lx0.157W 4.00mmx4.00mm 6.8muH
PDF
/
Inventory: 9785
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height Seated (Max) 0.047 1.20mm
Technical
RMS Current (Irms) 1.3A
Inductance Tolerance 20%
Case/Size Code 1616
Current - Saturation 900mA
Max DC Current 1.3A
DC Resistance (DCR) 150mOhm Max
Test Frequency 100kHz
Inductance 6.8μH
Current Rating 1.3A
Construction Epoxy Resin
Shielding Semi-Shielded
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±20%
Size / Dimension 0.157Lx0.157W 4.00mmx4.00mm
Series SRN4012
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
