SDR0906-270KL

Bourns Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description SDR0906 Nonstandard 0.492Lx0.413W 12.50mmx10.50mm 27muH
PDF
/
Inventory: 4938
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Height Seated (Max) 0.248 6.30mm
Height 6.3mm

Technical

Special Feature Q MEASURED AT 2.250 MHZ
DC Current 1.4A
Inductance Tolerance 10%
Case/Size Code 4137
Q Factor 35
Current - Saturation 2.2A
Quality Factor-Min (at L-nom) 35
Q @ Freq 35 @ 2.52MHz
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 15MHz
Max DC Current 1.4A
DC Resistance (DCR) 150mOhm Max
Test Frequency 1kHz
Inductance 27μH
Military Standard Not
Current Rating 1.4A
Depth 13mm
Number of Functions 1
Shielding NO
Packing Method TR
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±10%
Size / Dimension 0.492Lx0.413W 12.50mmx10.50mm
Series SDR0906
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 8
Terminal Shape GULL WING
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 18 Weeks
