SDR0906-103KSCL
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SDR0906 Nonstandard 0.492Lx0.413W 12.50mmx10.50mm 10mH
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 1203
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 10.4902mm
Length 12.4968mm
Height Seated (Max) 0.248 6.30mm
Technical
Current - Saturation 100mA
Inductance Frequency - Test 1kHz
Q @ Freq 100 @ 79.6kHz
Frequency - Self Resonant 1MHz
DC Resistance (DCR) 33Ohm Max
Test Frequency 1kHz
Inductance 10mH
Base Part Number SDR0906
Current Rating 40mA
Shielding Unshielded
Current Rating (Amps) 40mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.492Lx0.413W 12.50mmx10.50mm
Series SDR0906
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
