PM74SB-221K-RC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PM74SB Nonstandard 0.307Lx0.276W 7.80mmx7.00mm 220muH
PDF
/
Inventory: 5348
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2012
Series PM74SB
Size / Dimension 0.307Lx0.276W 7.80mmx7.00mm
Tolerance ±10%
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Resistance 1.18Ohm
Terminal Finish Tin/Copper (Sn/Cu)
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Depth 7.4mm
Current Rating 360mA
Military Standard Not
Inductance 220μH
Test Frequency 100kHz
DC Resistance (DCR) 1.18Ohm Max
Max DC Current 360mA
Frequency - Self Resonant 5MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Current - Saturation 550mA
Case/Size Code 3128
DC Current 360mA
Dimensions
Height 4.5mm
Height Seated (Max) 0.193 4.90mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
