PM7032S-331M-RC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PM7032S Nonstandard 0.276Lx0.276W 7.00mmx7.00mm 330muH
PDF
/
Inventory: 2863
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2011
Series PM7032S
Size / Dimension 0.276Lx0.276W 7.00mmx7.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
HTS Code 8504.50.80.00
Packing Method TR, EMBOSSED, 13 INCH
Shielding YES
Number of Functions 1
Construction Rectangular
Current Rating 220mA
Inductance 330μH
Test Frequency 100kHz
DC Resistance (DCR) 1.9Ohm Max
Max DC Current 220mA
Frequency - Self Resonant 6.1MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 46 @ 796kHz
Current - Saturation 240mA
Case/Size Code 2828
Dimensions
Height 3.2mm
Height Seated (Max) 0.134 3.40mm
Compliance
RoHS Status ROHS3 Compliant
