PM42S-180-RC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PM42S Nonstandard 0.189Lx0.189W 4.80mmx4.80mm 18muH
PDF
/
Inventory: 4268
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2012
Series PM42S
Size / Dimension 0.189Lx0.189W 4.80mmx4.80mm
Tolerance ±30%
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Silver/Nickel/Tin (Ag/Ni/Sn)
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Depth 5mm
Military Standard Not
Inductance 18μH
Test Frequency 100kHz
DC Resistance (DCR) 280mOhm Max
Max DC Current 920mA
Frequency - Self Resonant 30MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 7 @ 2.52MHz
Quality Factor-Min (at L-nom) 7
Current - Saturation 750mA
Case/Size Code 1919
DC Current 920mA
Dimensions
Height 1.8mm
Height Seated (Max) 0.118 3.00mm
Compliance
RoHS Status ROHS3 Compliant
