PM105S-221M
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PM105S Nonstandard 0.394Lx0.362W 10.00mmx9.20mm 220muH
PDF
/
Inventory: 7718
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -30°C~100°C
Packaging Tape & Reel (TR)
Published 2002
Series PM105S
Size / Dimension 0.394Lx0.362W 10.00mmx9.20mm
Tolerance ±20%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Packing Method TR
Shielding YES
Number of Functions 1
Reach Compliance Code unknown
Current Rating 540mA
Inductance 220μH
Test Frequency 1kHz
DC Resistance (DCR) 690mOhm Max
Max DC Current 540mA
Frequency - Self Resonant 5MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 3936
Dimensions
Height 5mm
Height Seated (Max) 0.217 5.50mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
