PM0603-6N8J image
Favorite
PM0603-6N8J image
Favorite

PM0603-6N8J

Bourns Inc.
RoHS
/
Package 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description PM0603 0603 (1608Metric) 0.065Lx0.041W 1.65mmx1.05mm 6.8nH
PDF
/
Inventory: 9929
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Terminal Shape ONE SURFACE
Weight 2.012816mg
Material - Core Ceramic
Shape/Size Description RECTANGULAR PACKAGE

Technical

Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Published 2002
Series PM0603
Size / Dimension 0.065Lx0.041W 1.65mmx1.05mm
Tolerance ±5%
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Current Rating 700mA
Case Code (Metric) 1608
Case Code (Imperial) 0603
Inductance 6.8nH
Test Frequency 250MHz
DC Resistance (DCR) 110mOhm
Max DC Current 700mA
Frequency - Self Resonant 5.8GHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 28 @ 250MHz
Quality Factor-Min (at L-nom) 28
Q Factor 28

Dimensions

Height 1mm
Height Seated (Max) 0.047 1.20mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
