CM252016-8R2KL
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
CM252016 Nonstandard 0.098Lx0.079W 2.50mmx2.00mm 8.2muH
PDF
/
Inventory: 10041
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height Seated (Max) 0.063 1.60mm
Height 1.6002mm
Technical
DC Current 105mA
Inductance Tolerance 10%
Q Factor 25
Q @ Freq 25 @ 7.96MHz
Frequency - Self Resonant 40MHz
Max DC Current 105mA
DC Resistance (DCR) 2.2Ohm Max
Test Frequency 7.96MHz
Inductance 8.2μH
Case Code (Imperial) 1008
Case Code (Metric) 2516
Military Standard Not
Current Rating 105mA
Depth 2mm
Shielding Unshielded
HTS Code 8504.50.80.00
Resistance 2.2Ohm
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Tolerance ±10%
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Series CM252016
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature -20°C~100°C
Physical
Material - Core Ferrite
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
