9250-472
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
9250 Axial 0.162Diax0.410L 4.11mmx10.41mm 4.7muH
PDF
/
Buying Options
Total Price: USD $1.82
Unit Price: USD $1.817054
≥1 USD $1.817054
≥200 USD $0.726034
≥500 USD $0.701089
≥1000 USD $0.689273
Inventory: 3526
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2005
Series 9250
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Tolerance ±10%
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Construction Flame Retardant Coat
Current Rating 380mA
Lead Length 25.4mm
Inductance 4.7μH
Test Frequency 7.9MHz
DC Resistance (DCR) 550mOhm Max
Max DC Current 380mA
Frequency - Self Resonant 70MHz
Inductor Application RF INDUCTOR
Q @ Freq 44 @ 7.9MHz
Quality Factor-Min (at L-nom) 44
Q Factor 44
Dimensions
Diameter 4.1148mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
