6000-1R5M-RC
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
6000 Radial Vertical Cylinder 0.354Dia 9.00mm 1.5muH
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8272
≥1 USD $0.8272
≥10 USD $0.69696
≥100 USD $0.494472
≥500 USD $0.393043
≥1000 USD $0.367682
≥3000 USD $0.355001
Inventory: 629
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Number of Pins 2
Material - Core Ferrite
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2007
Series 6000
Size / Dimension 0.354Dia 9.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Construction Bobbin Core
Current Rating 8.5A
Military Standard Not
Lead Pitch 5mm
Lead Length 10mm
Inductance 1.5μH
Test Frequency 7.96MHz
DC Resistance (DCR) 16mOhm Max
Max DC Current 8.5A
Frequency - Self Resonant 130MHz
Inductor Application RF INDUCTOR
Q @ Freq 20 @ 7.96MHz
Lead/Base Style Radial
Quality Factor-Min (at L-nom) 20
Q Factor 20
Inductance Tolerance 20%
DC Current 8.5A
Dimensions
Diameter 9mm
Height Seated (Max) 0.480 12.20mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
