5300-31-TR-RC
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
5300 Axial 0.160Diax0.500L 4.06mmx12.70mm 330muH
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.623628
≥1 USD $0.623628
≥200 USD $0.241574
≥500 USD $0.233696
≥1000 USD $0.228445
Inventory: 9529
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Material - Core Ferrite
Shape/Size Description TUBULAR PACKAGE
Technical
Operating Temperature -55°C~105°C
Packaging Tape & Reel (TR)
Published 2009
Series 5300
Size / Dimension 0.160Diax0.500L 4.06mmx12.70mm
Tolerance ±10%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Wirewound
Resistance 2.4Ohm
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Construction Conformal Coated
Current Rating 290mA
Military Standard Not
Lead Length 25.4mm
Inductance 330μH
Test Frequency 1kHz
DC Resistance (DCR) 2.4Ohm Max
Max DC Current 290mA
Frequency - Self Resonant 1.9MHz
Inductor Application RF INDUCTOR
Current - Saturation 170mA
DC Current 290mA
Dimensions
Diameter 4.06mm
Compliance
RoHS Status ROHS3 Compliant
