2105-V-RC
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
2100 Radial Vertical (Open) 0.860Diax0.450W 21.84mmx11.43mm 22muH
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.207118
≥1 USD $2.207118
≥10 USD $2.082189
≥100 USD $1.964321
≥500 USD $1.85314
≥1000 USD $1.748239
Inventory: 1152
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Radial, Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical (Open)
Terminal Shape WIRE
Number of Pins 2
Shape/Size Description CYLINDRICAL PACKAGE
Core Material Ferrite
Technical
Operating Temperature -55°C~105°C
Packaging Bulk
Published 2009
Series 2100
Size / Dimension 0.860Diax0.450W 21.84mmx11.43mm
Tolerance ±15%
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Type Toroidal
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Depth 11.43mm
Construction Vertical Mount
Current Rating 7A
Military Standard Not
Lead Pitch 8.382mm
Lead Diameter 1.07 mm
Inductance 22μH
Test Frequency 1kHz
DC Resistance (DCR) 15mOhm Max
Max DC Current 7A
Inductor Application HIGH CURRENT INDUCTOR
Lead/Base Style Radial
Inductance Tolerance 15%
DC Current 7A
RMS Current (Irms) 7A
Self Resonant Frequency 1kHz
Dimensions
Diameter 21.844mm
Height 11.43mm
Height Seated (Max) 11.43mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
