WW1008R-361K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED Fixed Inductor 125C 530MHz 1.1Ohm 360nH
PDF
/
Inventory: 6333
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 2.794mm
Length 2.921mm
Height Seated (Max) 2.032mm
Height 2.03mm
Technical
Special Feature Q MEASURED AT 100 MHZ
Inductance-Nom (L) 0.36 μH
DC Resistance (DCR) - Parallel 1.1Ohm
Case/Size Code 1008
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 45
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 530MHz
Max DC Current 470mA
Test Frequency 25MHz
Inductance 360 nH
Current Rating 470mA
Depth 2.79mm
Number of Functions 1
Shielding Unshielded
Packing Method TR, 7 Inch
HTS Code 8504.50.80.00
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 10%
Packaging Tape & Reel
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mount Surface Mount
