WW1008R-181K

API Delevan
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant WRAPAROUND DUAL ENDED Fixed Inductor 125C 750MHz 770mOhm 180nH
PDF
/
Inventory: 5479
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding Unshielded
Number of Functions 1
Depth 2.79mm
Current Rating 520mA
Inductance 180 nH
Test Frequency 25MHz
Max DC Current 520mA
Frequency - Self Resonant 750MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Quality Factor-Min (at L-nom) 45
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 1008
DC Resistance (DCR) - Parallel 770mOhm
Inductance-Nom (L) 0.18 μH
Special Feature Q MEASURED AT 100 MHZ
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e3
Tolerance 10%
Packaging Tape & Reel

Dimensions

Height 2.03mm
Height Seated (Max) 2.032mm
Length 2.921mm
Width 2.794mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ceramic
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mount Surface Mount
