M39010/03A561KR

API Delevan
RoHS
/
Package /
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR RoHS Compliant Axial WIRE Fixed Inductor 105C 4.7MHz 10.5Ohm 560muH
PDF
/
Inventory: 2138
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 10.414mm

Technical

Inductance-Nom (L) 560 μH
DC Resistance (DCR) - Parallel 10.5Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 60
Lead/Base Style Axial
Inductor Application RF INDUCTOR
Frequency - Self Resonant 4.7MHz
Max DC Current 90mA
Test Frequency 790kHz
Inductance 560 μH
Lead Diameter 0.635 mm
Reference Standard MIL-PRF-39010/03
Current Rating 90mA
Construction Molded
Number of Functions 1
Shielding Unshielded
Packing Method TR
HTS Code 8504.50.80.00
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Terminal Finish Tin/Lead (Sn63Pb37)
ECCN Code EAR99
Number of Terminations 2
Pbfree Code no
JESD-609 Code e0
Tolerance 10%
Packaging Bulk

Physical

Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Mount Through Hole
