SPD42R-103M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SPD42R Nonstandard 0.185Lx0.185W 4.70mmx4.70mm 10muH
PDF
/
Buying Options
Total Price: USD $3.82
Unit Price: USD $3.8192
≥1 USD $3.8192
≥10 USD $3.19704
≥100 USD $2.919136
≥500 USD $2.502192
≥1000 USD $2.293632
≥3000 USD $2.224147
Inventory: 518
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Weight 850mg
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2011
Series SPD42R
Size / Dimension 0.185Lx0.185W 4.70mmx4.70mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Packing Method TR, 7 Inch
Shielding YES
Number of Functions 1
Construction RECTANGULAR PACKAGE
Current Rating 580mA
Inductance 10μH
Test Frequency 100kHz
DC Resistance (DCR) 83mOhm Max
Max DC Current 580mA
Frequency - Self Resonant 37MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Case/Size Code 1919
Dimensions
Height 2.92mm
Height Seated (Max) 0.115 2.92mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
