SP1210-123K
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Wirewound Active J BEND Fixed Inductor -55C~125C 100kHz 1.3Ohm Max 12muH
PDF
/
Inventory: 8990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.101 2.57mm
Height 2.57mm
Technical
Current - Saturation 375mA
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 400mA
DC Resistance (DCR) 1.3Ohm Max
Test Frequency 100kHz
Inductance 12μH
Current Rating 400mA
Construction Rectangular
Depth 2.66mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn63Pb37)
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±10%
Size / Dimension 0.138Lx0.105W 3.51mmx2.66mm
Series SP1210
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape J BEND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
