SP1008R-273H

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active J BEND Fixed Inductor -55C~125C 100kHz 4.5Ohm Max 27muH
PDF
/
Inventory: 6522
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.095 2.41mm
Height 2.41mm

Technical

Saturation Current 285mA
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 159mA
DC Resistance (DCR) 4.5Ohm Max
Test Frequency 100kHz
Inductance 27μH
Current Rating 164mA
Depth 2.66mm
Number of Functions 1
Shielding YES
Packing Method TR, 7/13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±3%
Size / Dimension 0.115Lx0.105W 2.92mmx2.66mm
Series SP1008R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape J BEND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 45 Weeks
