SP1008-222H
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Wirewound Active J BEND Fixed Inductor -55C~125C 100kHz 437mOhm Max 2.2muH
PDF
/
Inventory: 4272
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.095 2.41mm
Height 2.41mm
Technical
Saturation Current 993mA
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 509mA
DC Resistance (DCR) 437mOhm Max
Test Frequency 100kHz
Inductance 2.2μH
Current Rating 524mA
Depth 2.66mm
Number of Functions 1
Shielding YES
Packing Method TR, 7/13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn/Pb)
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±3%
Size / Dimension 0.115Lx0.105W 2.92mmx2.66mm
Series SP1008
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape J BEND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 45 Weeks
