SDS680R-822M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active 2013 Fixed Inductor 50MHz 65mOhm 6.8muH ±20%
PDF
/
Inventory: 3981
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Packaging Tape & Reel (TR)
Published 2013
Series SDS680R
Size / Dimension 0.260Lx0.175W 6.60mmx4.45mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Composition Wirewound
Current Rating (Amps) 0.58mA
Shielding Shielded
Current Rating 580μA
Inductance 6.8μH
Test Frequency 100kHz
DC Resistance (DCR) 65mOhm
Frequency - Self Resonant 50MHz
Inductance Frequency - Test 100kHz
Dimensions
Height Seated (Max) 0.115 2.92mm
Length 6.604mm
Width 4.445mm
Compliance
RoHS Status ROHS3 Compliant
