S4924R-474J
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR ROHS3Compliant Active WRAPAROUND fixed air core inductor -55C~125C 5.7MHz 9.5Ohm Max 470muH
PDF
/
Inventory: 2752
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.230 5.84mm
Height 5.84mm
Technical
Case/Size Code 5225
Q Factor 60
Current - Saturation 43mA
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 60
Q @ Freq 60 @ 790kHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 5.7MHz
Max DC Current 178mA
DC Resistance (DCR) 9.5Ohm Max
Test Frequency 790kHz
Inductance 470μH
Current Rating 178mA
Construction Rectangular
Depth 6.35mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±5%
Size / Dimension 0.520Lx0.250W 13.21mmx6.35mm
Series S4924R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 45 Weeks
