S1812-394H
RoHS
/
Package 1812 (4532 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active WRAPAROUND Fixed Inductor -55C~125C 3.5MHz 18Ohm Max 390muH
PDF
/
Inventory: 6740
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1812 (4532 Metric)
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series S1812
Size / Dimension 0.189Lx0.134W 4.80mmx3.40mm
Tolerance ±3%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn63Pb37)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Depth 3.4mm
Current Rating 105mA
Case Code (Metric) 4532
Case Code (Imperial) 1812
Inductance 390μH
Test Frequency 790kHz
DC Resistance (DCR) 18Ohm Max
Max DC Current 105mA
Frequency - Self Resonant 3.5MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 40 @ 790kHz
Quality Factor-Min (at L-nom) 40
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 40
Dimensions
Height 3.4mm
Height Seated (Max) 0.134 3.40mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
