S1210R-682F
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 6.8UH 328MA 1.5 OHM
PDF
/
Inventory: 3291
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.101 2.57mm
Height 2.57mm
Technical
Q Factor 40
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 40
Q @ Freq 40 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 35MHz
Max DC Current 328mA
DC Resistance (DCR) 1.5Ohm Max
Test Frequency 7.9MHz
Inductance 6.8μH
Case Code (Imperial) 1210
Case Code (Metric) 3225
Current Rating 328mA
Depth 2.66mm
Number of Functions 1
Shielding YES
Packing Method TR
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±1%
Size / Dimension 0.138Lx0.105W 3.51mmx2.66mm
Series S1210R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case 1210 (3225 Metric)
Mounting Type Surface Mount
Mount Surface Mount
