S1210R-472F

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package 1210 (3225 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description FIXED IND 4.7UH 402MA 1 OHM SMD
PDF
/
Inventory: 7805
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.101 2.57mm
Height 2.57mm

Technical

Q Factor 40
Inductor Type GENERAL PURPOSE INDUCTOR
Quality Factor-Min (at L-nom) 40
Q @ Freq 40 @ 7.9MHz
Terminal Placement DUAL ENDED
Inductor Application RF INDUCTOR
Frequency - Self Resonant 40MHz
Max DC Current 402mA
DC Resistance (DCR) 1Ohm Max
Test Frequency 7.9MHz
Inductance 4.7μH
Case Code (Imperial) 1210
Case Code (Metric) 3225
Current Rating 402mA
Depth 2.66mm
Number of Functions 1
Shielding YES
Packing Method TR
HTS Code 8504.50.80.00
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e1
Tolerance ±1%
Size / Dimension 0.138Lx0.105W 3.51mmx2.66mm
Series S1210R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case 1210 (3225 Metric)
Mounting Type Surface Mount
Mount Surface Mount
