S1008R-122F
RoHS
RoHS compliant
RoHS compliantPackage 1008 (2520 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Fixed Inductors 1.2uH 1% .29ohm Shielded SMT Induc
PDF
/
Inventory: 9759
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 45 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1008 (2520 Metric)
Terminal Shape WRAPAROUND
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series S1008R
Size / Dimension 0.115Lx0.105W 2.92mmx2.66mm
Tolerance ±1%
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
HTS Code 8504.50.80.00
Packing Method TR, 13 Inch
Shielding YES
Number of Functions 1
Depth 2.66mm
Current Rating 625mA
Case Code (Metric) 2520
Case Code (Imperial) 1008
Inductance 1.2μH
Test Frequency 7.9MHz
DC Resistance (DCR) 290mOhm Max
Max DC Current 625mA
Frequency - Self Resonant 95MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 30 @ 7.9MHz
Quality Factor-Min (at L-nom) 30
Inductor Type GENERAL PURPOSE INDUCTOR
Q Factor 30
Dimensions
Height 2.41mm
Height Seated (Max) 0.095 2.41mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
