PTHF100-121VM
RoHS
/
Package Radial, Vertical (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Non-RoHS Compliant Toroidal Active WIRE fixed air core inductor 2MHz 65mOhm Max 100muH ±10%
PDF
/
Buying Options
Total Price: USD $54.85
Unit Price: USD $54.854275
≥1 USD $54.854275
≥200 USD $21.887356
≥500 USD $21.156071
≥1000 USD $20.795023
Inventory: 7155
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical (Open)
Terminal Shape WIRE
Material - Core Molybdenum Permalloy(MPP)
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Bulk
Published 2010
Series PTHF-VM
Size / Dimension 0.800Lx0.500W 20.32mmx12.70mm
Tolerance ±10%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Radial
ECCN Code EAR99
Type Toroidal
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Current Rating 3.24A
Lead Pitch 8.89mm
Lead Length 6.35mm
Lead Diameter 0.711 mm
Inductance 100μH
Test Frequency 1kHz
DC Resistance (DCR) 65mOhm Max
Max DC Current 3.24A
Frequency - Self Resonant 2MHz
Inductor Application POWER INDUCTOR
Inductance Frequency - Test 1kHz
Current - Saturation 3.4A
Dimensions
Height 24.76mm
Height Seated (Max) 0.975 24.76mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
